Android HttpConnection 文件上传

使用 HttpConnection 上传文件有点复杂，一般情况下都是用第三方库，不过，我们还是要实现一把，这样就更容易理解第三方库的某些设定

服务器端

如果使用 Servlet 开发一个服务器端比较复杂，我就直接用 GoLang 语言了

upserv.go

package main

import (
    "fmt"
    "io"
    "log"
    "net"
    "net/http"
    "os"
    "time"
)

func indexHandle(w http.ResponseWriter, r *http.Request) {
    defer func() {
        if err := recover(); err != nil {
            fmt.Println("获取页面失败")
        }
    }()

    // 上传页面
    w.Header().Add("Content-Type", "text/html")
    w.WriteHeader(200)
    html := `<!DOCTYPE html><meta charset="utf-8" />
<form id="uploadForm" enctype="multipart/form-data" action="/upload" method="POST">
<input type="file" id="file1" name="userfile" multiple /><input type="submit" value="上传">
</form>`

    io.WriteString(w, html)
}

func UploadServer(w http.ResponseWriter, r *http.Request) {

    defer func() {
        if err := recover(); err != nil {
            fmt.Println("文件上传异常")
        }
    }()

    if "POST" == r.Method {

        r.ParseMultipartForm(32 << 20)

        if r.MultipartForm != nil && r.MultipartForm.File != nil {

            fhs := r.MultipartForm.File["userfile"] //获取所有上传文件信息
            num := len(fhs)

            fmt.Printf("总文件数：%d 个文件", num)

            //循环对每个文件进行处理
            for n, fheader := range fhs {

                //获取文件名
                filename := fheader.Filename

                //结束文件
                file, err := fheader.Open()
                if err != nil {
                    fmt.Println(err)
                }

                //保存文件
                defer file.Close()
                f, err := os.Create(filename)
                defer f.Close()
                io.Copy(f, file)

                //获取文件状态信息
                fstat, _ := f.Stat()

                //打印接收信息
                fmt.Fprintf(w, "%s NO.: %d Size: %d KB Name：%s\n", time.Now().Format("2006-01-02 15:04:05"), n, fstat.Size()/1024, filename)
                fmt.Printf("%s NO.: %d Size: %d KB Name：%s\n", time.Now().Format("2006-01-02 15:04:05"), n, fstat.Size()/1024, filename)

            }
        }

        return
    } else {

        indexHandle(w, r)
    }
}

func main() {

    addrs, err := net.InterfaceAddrs()
    if err != nil {
        os.Stderr.WriteString("Oops:" + err.Error())
        os.Exit(1)
    }
    for _, a := range addrs {
        if ipnet, ok := a.(*net.IPNet); ok && !ipnet.IP.IsLoopback() {
            if ipnet.IP.To4() != nil {
                os.Stdout.WriteString(ipnet.IP.String() + "\n")
            }
        }
    }

    fmt.Println("Listening Port: 9999")
    http.HandleFunc("/", indexHandle)
    http.HandleFunc("/upload", UploadServer)
    err = http.ListenAndServe(":9999", nil)
    if err != nil {
        log.Fatal("ListenAndServe: ", err)
    }
}

把上面的代码保存为 upserv.go 然后打开终端或命令行提示符，输入以下命令直接运行

go serv.go

或者你可以下载我已经编译好的文件 /static/i/android/upserv.zip 里面有两个文件 upserv_macox 为苹果电脑下运行的，upserv_win 为 Windows 下运行的，打开终端或命令行提示符，输入以下命令直接运行

upserv.exe

成功运行后会输出以下提示

221.221.221.221
192.168.0.108
Listening Port: 9999

内网地址就是以 192.168 开头的，这时候你可以通过内网地址访问服务，比如我的 http://192.168.0.108:9999/ 运行

客户端

创建一个空的 Android 项目 cn.twle.android.HTTPUploadFile
在 app 上点击右键，选择 Folder - Assets Folder 创建一个 assets 目录
下载 /static/i/meimei.jpg 并且放到 assets 目录

修改 AndroidManifest.xml 中添加权限

<!-- 往SDCard写入数据权限 -->
<uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE"/>
<!-- 访问internet权限 -->
<uses-permission android:name="android.permission.INTERNET"/>

修改 activity_main.xml 创建布局

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:orientation="vertical"
    android:padding="16dp">

    <TextView
        android:layout_width="fill_parent"
        android:layout_height="wrap_content"
        android:text="文件名"
        android:textSize="18sp" />

    <EditText
        android:id="@+id/edit_fname"
        android:layout_width="fill_parent"
        android:layout_height="wrap_content"
        android:text="meimei.jpg" />

    <Button
        android:id="@+id/btn_upload"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="上传" />

    <TextView
        android:id="@+id/txt_result"
        android:padding="16dp"
        android:layout_width="fill_parent"
        android:layout_height="wrap_content"
        android:gravity="center" />
</LinearLayout>

创建一个上传帮助类 UploadHelper.java

package cn.twle.android.httpuploadfile;

import android.content.Context;

import java.io.BufferedReader;
import java.io.ByteArrayOutputStream;
import java.io.DataOutputStream;
import java.io.File;
import java.io.FileInputStream;
import java.io.InputStream;
import java.io.InputStreamReader;
import java.net.HttpURLConnection;
import java.net.URL;

public class UploadHelper
{

    public static Boolean upload(Context context, String[] uploadFiles, String remote_url) {

        String end = "\r\n";
        String twoHyphens = "--";
        String boundary = "4e7050f8f4615005b4cd";
        try {

            URL url = new URL(remote_url);
            HttpURLConnection conn = (HttpURLConnection) url.openConnection();

            // 发送POST请求必须设置如下两行

            conn.setDoInput(true);
            conn.setDoOutput(true);
            conn.setUseCaches(false);
            conn.setRequestMethod("POST");
            conn.setRequestProperty("Connection", "Keep-Alive");
            conn.setRequestProperty("Charset", "UTF-8");
            conn.setRequestProperty("Content-Type","multipart/form-data;boundary=" + boundary);

            DataOutputStream ds =
                    new DataOutputStream(conn.getOutputStream());
            for (int i = 0; i < uploadFiles.length; i++)  {

                String uploadFile  = uploadFiles[i];

                File f = new File(uploadFile);

                String filename = f.getName();
                ds.writeBytes(twoHyphens + boundary + end);
                ds.writeBytes("Content-Disposition: form-data; name=\"userfile\" ;filename=\"" +
                        filename + "\"" + end);

                ds.writeBytes(end);

                FileInputStream fStream = new FileInputStream(uploadFile);
                int bufferSize = 1024;
                byte[] buffer = new byte[bufferSize];
                int length = -1;
                while ((length = fStream.read(buffer)) != -1) {
                    ds.write(buffer, 0, length);
                }
                ds.writeBytes(end);
                fStream.close();
            }

            ds.writeBytes(twoHyphens + boundary + twoHyphens + end);
            ds.flush();
            ds.close();

            ((MainActivity)context).sendMessage("数据发送完毕，正在等待服务器返回\n");

            StringBuilder sb = new StringBuilder();

            ByteArrayOutputStream message = new ByteArrayOutputStream();

            byte buffer[] = new byte[1024];
            int len = 0;

            if ( conn.getResponseCode() == 200 ) {

                InputStream is = conn.getInputStream();
                String mes = conn.getResponseMessage();
                String heander = conn.getHeaderFields().toString();

                while ( (len = is.read(buffer) ) != -1) {

                    message.write(buffer,0,len);
                }

                sb.append(new String(message.toByteArray()));

                ((MainActivity) context).sendMessage(sb.toString() + "\n");

                message.close();
                is.close();
            } else {
                ((MainActivity)context).sendMessage("服务器返回状态:" + conn.getResponseCode());
            }
            conn.disconnect();

        } catch (Exception e) {

            ((MainActivity)context).sendMessage(e.getMessage() + "\n");
        }

        return true;
    }
}

修改 MainActivity.java

package cn.twle.android.httpuploadfile;

import android.content.Context;
import android.os.Environment;
import android.os.Handler;
import android.os.Message;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.widget.Button;
import android.widget.EditText;
import android.widget.TextView;
import android.widget.Toast;

import java.io.File;
import java.io.FileOutputStream;
import java.io.IOException;
import java.io.InputStream;
import java.io.OutputStream;

public class MainActivity extends AppCompatActivity implements View.OnClickListener {

    private EditText edit_fname;
    private Button btn_upload;
    private TextView txt_result;

    private  StringBuilder sb;

    private String remote_url = "http://192.168.0.105:9999/upload";

    private Handler handler = new Handler() {
        @Override
        public void handleMessage(Message msg) {

            txt_result.setText(sb.toString());
        }
    };

    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        sb = new StringBuilder();

        // 把 assets 下的 python.chm 拷贝到 sd
        File root = Environment.getExternalStorageDirectory();
        File dir = new File(root.getPath() + "/assets");

        if ( !dir.exists()) {
            Boolean ok = dir.mkdirs();
        }

        String modelFilePath = "meimei.jpg";
        Assets2Sd(this, modelFilePath, dir.getPath() );

        edit_fname = (EditText) findViewById(R.id.edit_fname);
        btn_upload = (Button) findViewById(R.id.btn_upload);
        txt_result = (TextView) findViewById(R.id.txt_result);

        btn_upload.setOnClickListener(this);
    }

    @Override
    public void onClick(View v) {
        final String filename = edit_fname.getText().toString();

        if (Environment.getExternalStorageState().equals(Environment.MEDIA_MOUNTED)) {
            final File file = new File(Environment.getExternalStorageDirectory().getPath() + "/assets/",filename);
            if (file.exists()) {

                new Thread(new Runnable() {
                    @Override
                    public void run() {
                        sendMessage("开始上传文件:" + file.getAbsolutePath() + "\n");
                        UploadHelper.upload(MainActivity.this,new String[] {file.getAbsolutePath()},remote_url);
                    }
                }).start();

            } else {
                sendMessage("文件并不存在~\n");
            }
        } else {
            sendMessage("SD卡不存在或者不可用\n");
        }
    }

    public void sendMessage(String msg) {
        sb.append(msg);
        handler.sendEmptyMessage(0x1001);
    }

    /***
     * 调用方式
     *
     * String path = Environment.getExternalStorageDirectory().toString() + "/" + "Tianchaoxiong/useso";
     String modelFilePath = "Model/seeta_fa_v1.1.bin";
     Assets2Sd(this, modelFilePath, path + "/" + modelFilePath);
     *
     * @param context
     * @param fileAssetPath assets中的目录
     * @param SdPath 要复制到sd卡中的目录
     */
    public static void Assets2Sd(Context context, String fileAssetPath, String SdPath){
        //测试把文件直接复制到sd卡中 fileSdPath完整路径

        String dstFile = SdPath + "/" + fileAssetPath;
        File file = new File(dstFile);
        if (!file.exists()) {
            try {

                InputStream myInput;
                OutputStream myOutput = new FileOutputStream(dstFile);
                myInput = context.getAssets().open(fileAssetPath);
                byte[] buffer = new byte[1024];
                int length = myInput.read(buffer);
                while(length > 0)
                {
                    myOutput.write(buffer, 0, length);
                    length = myInput.read(buffer);
                }

                myOutput.flush();
                myInput.close();
                myOutput.close();

            } catch (IOException e) {
                e.printStackTrace();
            }
        } else {
        }

    }

}
